ABB CI511-ETHCAT: S500 Interface module

Series#: ABB AC500 Communication interface modules

Product Details

General Information Extended Product Type: CI511-ETHCAT Product ID: 1SAP220900R0001 ABB Type Designation: CI511-ETHCAT EAN: 4016779664820 Catalog Description: Interface module. EtherCAT slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch functionality (CI511-ETHCAT) Long Description: CI511-ETHCAT: S500 Interface module. EtherCAT slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch functionality. Extendable by up to 10 I/O modules.

Specification

Download A Manual

Ordering

CN8:

85389091

Invoice Description:

Interface module. EtherCAT slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch functionality (CI511-ETHCAT)

Made To Order:

No

Minimum Order Quantity:

1 piece

Order Multiple:

1 piece

Selling Unit of Measure:

piece

Dimensions

Product Net Weight:

0.138 kg

Product Net Depth / Length:

62 mm

Product Net Height:

76 mm

Product Net Width:

67.5 mm

Gross Weight:

0.162 kg

Package Level 1 Depth / Length:

84 mm

Package Level 1 Height:

72 mm

Package Level 1 Width:

71 mm

Package Level 1 Units:

1 carton

Technical

Function:

EtherCAT slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A. Cam switch functionality

Number of Hardware Interfaces:

Industrial Ethernet 2

Other 0

Parallel 0

RS-232 0

RS-422 0

RS-485 0

Serial TTY 0

USB 0

Wireless 0

Analog Inputs:

4

Analog Outputs:

2

Number of Digital Inputs:

8

Number of Digital Outputs:

8

Number of Digital Configurable I/Os:

0

Input Voltage Type:

DC

Input Voltage (Uin):

24 V DC

Input Current:

5 mA

Delay Time (τ):

0.1 … 32 ms

Output:

Transistor

Output Voltage Type:

DC

Output Current:

0.5 A

Output Voltage Maximum:

20.4 … 28.8 V

Degree of Protection:

IP20

Supply Voltage:

20.4 ... 28.8 V DC

Additional Information

Product Main Type:

CI511

Product Name:

Distributed Automation I/Os

Classifications

eClass:

27-24-26-07

ETIM 8:

EC001604 - Fieldbus, decentr. periphery - communication module

UNSPSC:

32151705

Environmental

SCIP:

8070cf6d-0c4e-45d4-a548-e34b150e30d2 Germany (DE)

WEEE B2C / B2B:

Business To Business

WEEE Category:

5. Small Equipment (No External Dimension More Than 50 cm)
