Siemens SIMATIC S7-200 CPU 224XP PLC AC DC RLY AI AO | 6ES7214-2BD23-0XB0

Part Name: Siemens SIMATIC S7-200 PLC

Model No.: 6ES7214-2BD23-0XB0, CPU 224XP Compact Unit

Power: AC Power Supply, with voltage range from 120V to 230V

Input:

• 14 DI (Digital Inputs), DC (Direct Current)

Output:

• 10 DO (Digital Outputs), Relay outputs

Analog Input:

• 2 AI (Analog Inputs), Analog potentiometer inputs with 8-bit resolution

Analog Output:

• 1 AO (Analog Output)

Storage:

• Program Memory: 12/16 KB (varies by model), RAM

• Data Memory: 10 KB, RAM

Interface:

• 2 RS-485 communication ports supporting PPI (Point-to-Point Interface) and user-programmable interface

Built-in Features:

• Modular design allows for integration into larger systems or standalone use

• May include support for high-speed counters and pulse outputs (depending on specific model features)

• Compact design ideal for space-constrained applications

Programming Software:

• Uses MicroWin programming software for intuitive and efficient program development

Application Scenarios:

• Mid-range automation tasks, balancing cost and performance

• Provides increased functionality with analog inputs and outputs for more complex control systems

• Easily scalable with modular expansion options (where applicable)

• Integration with other Siemens S7-200 series PLCs or larger control systems

Environmental Adaptability:

• Typically designed for industrial environments with appropriate protection measures for dust, temperature variations, and vibration

Overall, the 6ES7214-2BD23-0XB0 CPU 224XP Compact Unit offers a versatile solution for automation tasks requiring a mix of digital and analog control, all in a compact and economical package.
