SIMATIC S7-200 PLC CPU 226 with the product code 6ES7216-2BD23-0XB0 offers a comprehensive set of specifications, perfectly suited for a wide range of automation control applications.
Basic Information
Product Name: SIMATIC S7-200 CPU 226
Part Number: 6ES7216-2BD23-0XB0
Brand: Siemens
Electrical Characteristics
Power Supply: AC, compatible with a voltage range spanning from 100V to 240V, ensuring global applicability
Output Type: Relay Outputs, providing versatility for a broad spectrum of industrial loads
Output Ratings: The relay outputs are capable of switching up to 30Vdc or 240Vac, catering to various control requirements
Input/Output Points
Input Points: 24 DC Digital Inputs, allowing for precise monitoring of various process variables
Output Points: 16 Relay Digital Outputs, offering ample control over external devices and systems
Memory Capacity
Program Memory: The CPU 226 boasts a program memory ranging from 16KB to 24KB, depending on the specific model, sufficient for complex automation logic
Data Memory: With 10KB of data memory, it ensures smooth handling of process data and variables
Communication & Interfaces
Communication Interfaces: Equipped with 2 RS-485 communication ports, supporting both PPI (Point-to-Point Interface) and freely programmable SS (Serial Slave), enabling seamless integration into automation networks
Built-in Features
Real-time clock, enabling time-based automation and scheduling
Support for high-speed counters, ideal for applications requiring precise counting and timing
High-speed pulse outputs, allowing for precise control of stepper motors and servo drives
Other Features
CPU Processing Power: With each instruction processed in just 0.22μs, the CPU 226 guarantees fast and responsive automation control
Modular Expansion: The modular design supports expansion up to a total of 256 I/O points (excluding S7-221), providing scalability for growing automation needs
Environmental Adaptability: Suitable for operation in extended temperature ranges, ensuring reliable performance in various industrial environments
Programming Software: Leveraging MicroWin programming software, further enhanced for efficiency, it significantly reduces program development time
Application Scenarios
Small-scale Automation Tasks: The CPU 226 is ideally suited for economically and efficiently executing simple to moderately complex automation tasks
Modular Design: The consistent modular design not only simplifies maintenance but also facilitates the creation of low-cost, customized products and scalable solutions
Integration with Other Controllers: Siemens S7-200 micro PLCs, including the CPU 226, can be seamlessly integrated with other controllers, either as stand-alone solutions or as part of larger automation systems.
