| Specificatio | AJ65SBTB2-8A AC input modul |
| Number of input points | 8 points |
| Insulation method | Photocoupler |
| Rated input voltage | 100 to 120 V AC 50/60 Hz |
| Rated input current | Approx. 7 mA (100 V AC 60 Hz) |
| Operating voltage range | 85 to 132 V AC (50/60 Hz ±5 %) |
| Max. simultaneous ON | 100 % simultaneous ON (at 100 V AC) |
| input points | 60 % simultaneous ON (at 132 V AC) |
| Inrush current | Max. 200 mA within 1 ms (at 132 V AC) |
| ON voltage/ON current | 80 V AC or higher/5 mA or higher |
| OFF voltage/OFF current | 30 V AC or lower/1 mA or lower |
| Input resistance | Approx. 15 k W (60 Hz), Approx. 18 k W (50 Hz) |
| Number of stations occupied | 1 station 32 points assignment (use 8 points) |
| I/O module | Voltage20.4 to 26.4 V DC(ripple ratio: within 5 %) |
| power supply |
| Withstand voltage | 1780 V AC between all AC external terminals and ground, rms/ 3 cycles (2000 m above sea level) |
| 500 V AC for 1 minutes between all DC external terminals and ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance |
| tester between all AC external terminals and ground |
| 10 M W or higher, measured with a 500 V DC insulation resistance tester between all DC external terminals and ground |
| Weight (kg)(lb.) | 0.2 (0.44) |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power supply terminal), Direct-type 18-point terminal block (I/O power |
| supply area) (M3 screw) |
| Applicable solderless terminal | • RAV1.25-3.5 (in conformance with JIS-C2805) [Applicable wire size: 0.3 to1.25 mm2] |
| • V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) |
| • 2-3N, 2-3S (NICHIFU TERMINAL INDUSTRIES Co., Ltd.) |
| [Applicable wire size: 1.25 to 2.0 mm2] |
|
|
| Number of input points | AJ65SBTB2N-16A 100 V AC inputmodule 16 points |
| Insulation method | Photocoupler |
| Rated input voltage | 100 to 120 V AC 50/60 Hz |
| Rated input current | Approx. 7 mA (100 V AC 60 Hz) |
| Operating voltage range | 85 to 132 V AC (50/60 Hz ±5 %) |
| Max. simultaneous input | 100 % simultaneous ON (at 100 V AC) |
| points | 60 % simultaneous ON (at 132 V AC) |
| Inrush current | Max. 200 mA within 1 ms (at 132 V AC) |
| ON voltage/ON current | 80 V AC or higher/5 mA or higher |
| OFF voltage/OFF current | 30 V AC or lower/1 mA or lower |
| Input resistance | Approx. 15 k W (60 Hz), Approx. 18 k W (50 Hz) |
| Common method | 16 points/1 common (terminal block 2-wire type) |
| Number of stations | 1 station 32 points assignment (use 16 points) |
| occupied |
| Noise durability | Simulator noise 1500 Vp-p, noise width 1 ms, noise carrier |
| frequency 25 to 60 Hz (noise simulator condition) Fast transient/noise burst IEC61000-4-4 : 1 kV |
| Withstand voltage | 1780 V AC between all AC external terminals and ground, |
| rms/ 3 cycles (2000 m above sea level) |
| 500 V AC for 1 minutes between all DC external terminals and ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance |
| tester between all AC external terminals and ground |
| 10 M W or higher, measured with a 500 V DC insulation resistance tester between all DC external terminals and ground |
| Weight (kg)(lb.) | 0.25 (0.55) |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power |
| supply terminal), Direct-type 34-point terminal block (I/O power supply area) (M3 screw) |
| Applicable solderless terminal | • RAV1.25-3.5 (in conformance with J2IS-C2805) |
| [Applicable wire size: 0.3 to1.25 mm ] |
| • V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) |
| • 2-3N, 2-3S (NICHIFU TERMINAL IND2USTRIES Co., Ltd.) |
| [Applicable wire size: 1.25 to 2.0 mm ] |
|
