| Part Number | AJ65SBTB1-16D1 |
| Number of input points | 8 points | Number of output points | 16 points |
| Insulation method | Photocoupler | Insulation method | Photocoupler |
| Rated input voltage | 24 V DC | Rated load voltage | 24 V DC |
| Rated input current | Approx. 7 mA | Operating load voltage range | 19.2 to 26.4 V DC(ripple ratio: within 5 %) |
| Operating voltage range | 19.2 to 26.4 V DC (ripple ratio: within 5 %) | Max. load current | 0.5 A/point |
| (when all point 5 are ON : 0.225 A/1 point) 3.6 A/common |
| Max. simultaneous input | 100% | Max. inrush current | 1.0 A 10 ms or lower |
| points |
| ON voltage/ON current | 14 V or higher/3.5 mA or higher | Leakage current at OFF | 0.25 mA or lower |
| OFF voltage/OFF current | 6 V or lower/1.7 mA or lower | Voltage drop at ON | 0.3 V or lower (TYP)0.5 A |
| 0.6 V or lower (MAX)0.5 A |
| Input resistance |
| Output form | Sink type with overload protection frunction, overvoltage protection function, overheat protection function. |
| A pprox. 3.3 k W |
| Input form | Sink type | Surge suppression | Zener diode |
| Common wiring method | 16 points/1 common (Terminal block single wire type) |
| Number of stations occupied | 1 station 32 points assignment (use 16 points) |
| Noise durability | DC type noise voltage 500 Vp-p, noise width 1 ms, noise carrier frequency 25 to 60 Hz(noise simulator |
| condition) |
| Withstand voltage | 500 V AC for 1 minute between all DC external terminals and ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance tester between all DC external |
| terminals and ground |
| Weight (kg) (lb.) | 0.18 (0.4) |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power supply terminal), |
| Direct-type 18-point terminal block (I/O power supply area) (M3 screw) |
| Applicable solderless terminal | • RAV1.25-3.5(in conformance with JIS-C2805) [Applicable wire size: 0.3 to1.25 mm2] |
| • V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) |
| • 2-3N, 2-3S (NICHIFU TERMINAL INDUSTRIES Co., Ltd.) [Applicable wire size: 1.25 to 2 mm2] |
|
|
|
|
| Part Number | AJ65SBTB1-16DT1 |
| Number of input points | 8 points | Number of output points | 8 points |
| Insulation method | Photocoupler | Insulation method | Photocoupler |
| Rated input voltage | 24 V DC | Rated load voltage | 24 V DC |
| Rated input current | Approx. 5 mA | Operating load voltage range | 19.2 to 26.4 V DC(ripple ratio: within 5 %) |
| Operating voltage range | 19.2 to 26.4 V DC | Max. load current | 0.5 A/point |
| (ripple ratio: within 5 %) | 2.4 A/common |
| Max. simultaneous input | 100% | Max. inrush current | 1.0 A 10 ms or lower |
| points |
| ON voltage/ON current | 15 V or higher/3.0 mA or higher | Leakage current at OFF | 0.25 mA or lower |
| OFF voltage/OFF current | 3 V or lower/0.5 mA or lower | Voltage drop at ON | 0.3 V or lower (TYP)0.5 A |
| 0.6 V or lower (MAX)0.5 A |
| Input resistance | A pprox. 4.7 k W | Output form | Sink type |
| Input form | Sink type | Surge suppression | Zener diode |
| Common wiring method | 16 points/1 common (Terminal block single wire type) |
| Number of stations occupied | 1 station 32 points assignment (use 16 points) |
| Noise durability | DC type noise voltage 500 Vp-p, noise width 1 ms, noise carrier frequency 25 to 60 Hz(noise simulator |
| condition) |
| Withstand voltage | 500 V AC for 1 minute between all DC external terminals and ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance tester between all DC external |
| terminals and ground |
| Weight (kg) (lb.) | 0.18 (0.4) |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power supply terminal), |
| Direct-type 18-point terminal block (I/O power supply area) (M3 screw) |
| Applicable solderless terminal | • RAV1.25-3.5(in conformance with JIS-C2805) [Applicable wire size: 0.3 to1.25 mm2] |
| • V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) |
| • 2-3N, 2-3S (NICHIFU TERMINAL INDUSTRIES Co., Ltd.) [Applicable wire size: 1.25 to 2 mm2] |
