12 inch widescreen touch panel with color display and 10 function keys
HMI devices for tasks in the medium performance range for the use in PROFINET or PROFIBUS networks.
The KTP1200 Basic is the ideal HMI-component for the medium and upper S7-1200 controller systems. With regard to screen size and resolution the KTP1200 meets higher requirements.
| Technical Data | KTP1200 Basic | KTP1200 Basic DP |
| Hardware | ||
| Display | 12 inch TFT display, 64K colors | |
| Resolution | 1280 x 800 | |
| Control elements | Touch screen / 10 Function keys | |
| User memory | 10 MB | |
| Interfaces | 1 x RJ 45 for PROFINET | 1 x RS 485 for PROFIBUS/MPI |
| 1 x USB host | 1 x USB host | |
| Degree of protection | IP 65, NEMA 4x (front if mounted) / IP 20 rear | |
| Installation cutout | 310 x 221 mm (W x H) | |
| Front panel | 330 x 245 mm (W x H) | |
| Device depth | 62 mm | |
| Software functions | ||
| Configuration software | WinCC Basic (TIA Portal) V13 or higher | |
| Messages | 1000 | |
| Message classes | 32 | |
| Process screens | 100 | |
| Tags | 800 | |
| Vector graphics | x | |
| Bar graphics | x | |
| Curve diagrams | f (t) | |
| Recipes | 50 | |
| Archiving | x | |
| Article No.: | 6AV2123-2MB03-0AX0 | 6AV2123-2MA03-0AX0 |
